Bowers 10-20mm Analogue Bore Micrometer Set SXTA4M

Details

XT analogue bore gauge is an economical solution to accurate shop-floor bore measurement. The extended mechanical travel of these advanced two or three point gauges ensures that exchanging measuring anvils is now unnecessary. Their wide application range, 2-300mm, rugged construction and easy read scale, ensure both accuracy and ease of use.

Brand :Bowers

Manufacturer Part Number :SMXTA4M

Additional Information :Includes: individual instrument, setting ring with UKAS certificate

Features & Benefits : Tungsten carbide measuring faces on all 3-point heads from 12.5mm
Extensions available for deep hole measurement
Ratchet stop to ensure consistent measurement
setting ring included with individual instrument and set
UKAS certificates supplied as standard with all setting rings
UKAS certificate supplied as standard with all XT mechanical micrometres
Serial number on all gauges
Bore gauges manufactured according to DIN 863 part 4
Supplied in fitted wooden case

Range (mm) :10 – 20

Model :SXTA4M

Type :Analogue Bore Gauge Set

Graduation :0.005 mm
