Bowers 100mm-125mm XT Digital Bore Micrometer

Details

XT3 Digital internal micrometres offer a new ergonomic design including a larger and clearer LCD display – along with IP67 electronics protection, proximity output with optional built-in Bluetooth. both allow bi-directional communication giving greater flexibility for data acquisition and storage. The extended mechanical travel of the XT range means that special heads can also be manufactured to accommodate users most awkward measuring problems.

Brand :Bowers

Accuracy (mm) :0.006

Manufacturer Part Number :XTD100M-BT

Features & Benefits : Individual instruments supplied with digital display unit head, ring and UKAS
New ergonomic design with larger and clearer LCD display
IP67 electronics
Simple 2-button operation
4 pre-set memories
Proximity output with optional built-in Bluetooth
Bi-directional communication
Tungsten carbide measuring faces on all 3-point heads from 12.5mm
Extensions available for deep hole measurement
Ratchet stop to ensure consistent measurement
125mm setting ring included
Depth 115mm
UKAS certificates supplied as standard with all setting ring and gauges
Serial number on all digital readouts and measuring heads
Bore gauges manufactured according to DIN 863 part 4
Supplied in fitted wooden case

Range (mm) :100 – 125

Model :XTD100M-BT

Type :Digital Bore Gauge

Graduation :0.001 mm;0.00005 in
